3" 75mm Tank Pressure Manometer 1 MPa Chromed Steel Utility
Pressure Gauge
Description
To accommodate many different applications, manufacturers make many
different types of pressure gauges. Examples of these include water
pressure gauges, air pressure gauges, oil pressure gauges,
temperature gauges, gas pressure gauges, fuel pressure gauges,
differential pressure gauges, and vacuum pressure gauges. Some of
the uses of these gauges are more obvious than others.
Applications
For gaseous and liquid media that are not highly viscous or
crystallising and will not attack copper alloy parts.
Pneumatics
Heating and air-conditioning technology
Medical engineering
Special features
Reliable and cost-effective
Design per EN 837-1
Nominal size 40, 50, 63, 80, 100 and 160
Scale ranges up to 0 ... 400 bar
Specifications
Design | EN 837-1 |
Nominal size | 75mm, 3" |
Accuracy | 1.0 |
| Pressure range | 1 MPa (customized) |
Pressure limitation | Steady: 3/4 x full scale value
Fluctuating: 2/3 x full scale value
Short time: full scale value |
Permissible temperature | Ambient: -20 ... +60 °C
Medium: +60 °C maximum |
Temperature effect | When the temperature of the measuring system deviates from the
reference temperature (+20 °C): max. ±0.4 %/10 K of the span |
Process connection | Brass |
Pressure element | Brass, C-type or helical type Bourdon tube |
| Movement | Brass |
| Dial | Aluminium, white, with pointer stop pin
Black/red lettering |
| Pointer | Aluminium |
| Case | Chromed steel |
| Window | PC |
| Options | Other process connection
Surface mounting flange
Mounting bracket |
Dimensions
lower mount (radial)
| Dial Size | Dimensions in mm | Weight in kg |
| a | b | D | G | h | SW |
| 40 | 9.5 | 26 | 39 | G1/4 | 36 | 14 | 0.08 |
| 50 | 10 | 27.5 | 49 | G1/4 | 45 | 14 | 0.10 |
| 63 | 9.5 | 27.5 | 62 | G1/4 | 53.5 | 14 | 0.13 |
| 80 | 11.5 | 30 | 79 | G1/2 | 72 | 22 | 0.18 |
| 100 | 11.5 | 30.5 | 99 | G1/2 | 83.5 | 22 | 0.21 |
| 160 | 15.5 | 42 | 160 | G1/2 | 115.5 | 22 | 0.85 |
back mount (axial)
| Dial Size | Dimensions in mm | Weight in kg |
| b1 | b2 | D | G | SW |
| 40 | 26 | 42 | 39 | G1/8 | 14 | 0.06 |
| 50 | 29.5 | 47.5 | 49 | G1/4 | 14 | 0.07 |
| 63 | 29 | 47 | 62 | G1/4 | 14 | 0.08 |
| 80 | 32 | 49 | 79 | G1/4 | 14 | 0.11 |
| 100 | 31 | 49 | 99 | G1/4 | 14 | 0.26 |
Ordering information
Model / Dial size / Pressure Range / Process connection / Options
